Description
PREORDER: Please allow up to 14 business days for turnaround.
P41 Purifier (Stainless Steel) with Refillable Purifier Element (Stainless Steel)
2nd and 3rd Stage Water Condensate & Oil Separator
Intercoolers (Stainless Steel)
Aftercooler (Stainless Steel)
Priority Valve (Pressure Maintaining Valve)
Check Valve
Safety Valve at Each Stage
Oil Level Glass
Electrostatically Painted Portable Chassis
Manual Start / Stop
Manual Condensate Drain
Power Cable
Thermal Overload Protection for Electric Motor
Control Panel: On / Off Buttons & Hourmeter
2* Filling Hose (Yokes, Filling Valves, Pressure Gauges, DIN Adapters)
Air Quality complies with EN 12021, Grade E and D
ADDITIONAL OPTIONS INCLUDED
Dual Pressure System 225-345 Bar / 3260-5000 Psi
Stainless Chassis
Extra Filling Hoses
Disposable Filter Cartridge
Electric Engine Drive
SPECIFICATIONS
Working Pressure Range: 1450-5000 psi
CFM: 10.7
Voltage (Amp): 220V (18 amp)
Motor Power: 10 hp
RPM: 1600
No. of Stages: 3
Purifier Size: P41
No. of Filling Hoses: 2
Weight (lbs): 370
Dimensions (WxLxH) Inches: 20 x 44 x 27
