Tippmann 98 Custom ACT Parts

No. Part Name Price
(1)
98 PS BLACK NICKEL AC RECEIVER - RIGHT 98 PS BLACK NICKEL AC RECEIVER - RIGHT
$74.95
(2)
BLACK HEX NUT #10-32X3/8 BLACK HEX NUT #10-32X3/8
$1.95
(3)
HEX NUT BLACK HHC #10-32 x 5/16 HEX NUT BLACK HHC #10-32 x 5/16
$1.95
(4)
PIN DOWEL W/KNURL 1/8 X 5/8 PIN DOWEL W/KNURL 1/8 X 5/8
$1.95
(5)
PINS DOWEL BLACK 1/8 X 5/8 PINS DOWEL BLACK 1/8 X 5/8
$1.95
(6)
PIN DOWEL W/KNURL 3/32 X 5/16 PIN DOWEL W/KNURL 3/32 X 5/16
$1.95
(7)
A-5/98 SEAR A-5/98 SEAR
$14.95
(8)
COMP SPRING 0.575FL - 0.189OD-GREEN COMP SPRING 0.575FL - 0.189OD-GREEN
$1.95
(9)
98 CUSTOM TRIGGER ASSEMBLY 98 CUSTOM TRIGGER ASSEMBLY
$22.95
(9.1)
98 CUSTOM TRIGGER 98 CUSTOM TRIGGER
$14.95
(9.2)
98 TRIGGER RETURN SLIDE 98 TRIGGER RETURN SLIDE
$1.95
(9.3)
PIN DOWEL 1/8D X 1/4L NO CHAMFER PIN DOWEL 1/8D X 1/4L NO CHAMFER
$1.95
(9.4)
A-5 & 98 TRIGGER RETURN SLIDE SPRING - YELLOW A-5 & 98 TRIGGER RETURN SLIDE SPRING - YELLOW
$2.95
(10)
A-5 & 98 TRIGGER RETURN SLIDE SPRING - YELLOW A-5 & 98 TRIGGER RETURN SLIDE SPRING - YELLOW
$2.95
(11)
98 SAFETY 98 SAFETY
$10.95
(11.2)
O-RING - RED BUNA SAFETY 1/8 X 1/4 X 1/16 O-RING - RED BUNA SAFETY 1/8 X 1/4 X 1/16
$1.95
(11.3)
O-RING BUNA SAFETY 1/8 X 1/4 X 1/16 O-RING BUNA SAFETY 1/8 X 1/4 X 1/16
$1.95
(12)
98 TRIGGER GUARD 98 TRIGGER GUARD
$10.95
(13)
NUTS MS SQ SH 10-32 NUTS MS SQ SH 10-32
$1.95
(14)
BALL LATCH - ORANGE BALL LATCH - ORANGE
$3.95
(15)
O-RING 2-116-N70 O-RING 2-116-N70
$1.95
(16)
NUTS HH 6-32 NUTS HH 6-32
$1.95
(17)
98 PS GASLINE W/NUT 98 PS GASLINE W/NUT
$35.95
(18)
98 FRONT SIGHT SPRING 98 FRONT SIGHT SPRING
$1.95
(19)
98 PS FRONT SIGHT 98 PS FRONT SIGHT
$4.95
(20)
98 PS FRONT SIGHT PIN 98 PS FRONT SIGHT PIN
$1.95
(21)
A-5/98/X7 FRONT BOLT A-5/98/X7 FRONT BOLT
$7.95
(22)
O-RING BUNA BLACK 2-015 O-RING BUNA BLACK 2-015
$1.95
(23)
98 PS BLACK NICKEL AC RECEIVER - LEFT FRONT 98 PS BLACK NICKEL AC RECEIVER - LEFT FRONT
$44.95
(24)
BOLT LHSHCS 10-32 X .625 BOLT LHSHCS 10-32 X .625
$1.95
(25)
98 CUSTOM FRONT GRIP 98 CUSTOM FRONT GRIP
$14.95
(26)
BOLT LHSHCS 10-32 X .625 BOLT LHSHCS 10-32 X .625
$1.95
(28)
98 Platinum Series Power Tube Machined 98 Platinum Series Power Tube Machined
$16.95
(29)
SCREW SHSS 5/16-24 X 7/16 SCREW SHSS 5/16-24 X 7/16
$1.95
(30.1)
98 PS VALVE BODY 98 PS VALVE BODY
$44.95
(30.2)
O-RING CAST URETHANE 2-019, 90A O-RING CAST URETHANE 2-019, 90A
$2.95
(30.3)
98 VALVE PLUG 98 VALVE PLUG
$11.95
(30.4)
O-RING CAST URETHANE 2-012 O-RING CAST URETHANE 2-012
$2.95
(30.5)
98 VALVE SPRING 98 VALVE SPRING
$2.95
(30.6)
VALVE SEAT VALVE SEAT
$11.95
(30.7)
VALVE PLUNGER VALVE PLUNGER
$11.95
(30.8)
VALVE SNAP RINGS VALVE SNAP RINGS
$1.95
(32)
98 PS BLACK NICKEL AC RECEIVER - LEFT REAR 98 PS BLACK NICKEL AC RECEIVER - LEFT REAR
$52.95
(33)
98 CUSTOM NAME PLATE 98 CUSTOM NAME PLATE
$4.95
(34)
98 PS GASLINE W/NUT 98 PS GASLINE W/NUT
$35.95
(35)
98 PS TANK ADAPTER 98 PS TANK ADAPTER
$28.95
(36)
SCREW BHCS 10-32 X 7/8 SCREW BHCS 10-32 X 7/8
$1.95
(37)
SCREW BHCS 10-32 X 7/8 SCREW BHCS 10-32 X 7/8
$1.95
(39)
O-RING BUNA 13/16 X 1 X 3/32 -70A O-RING BUNA 13/16 X 1 X 3/32 -70A
$1.95
(40)
O-RING BUNA 13/16 X 1 X 3/32 -70A O-RING BUNA 13/16 X 1 X 3/32 -70A
$1.95
No. Part Name Price
(40.1)
98 FEED ELBOW 98 FEED ELBOW
$6.95
(40.2)
98 FEED ELBOW LATCH 98 FEED ELBOW LATCH
$4.95
(40.3)
SCREW 8-32 X .250 PH TRI-LOBE BLACK SCREW 8-32 X .250 PH TRI-LOBE BLACK
$1.95
(40.4)
PIN DOWEL W/KNURL 1/8 X 5/8 PIN DOWEL W/KNURL 1/8 X 5/8
$1.95
(40.5)
SCREW SHCS 1/4-20 X 1 SCREW SHCS 1/4-20 X 1
$1.95
(40.6)
WASHER TPHS 8-32 X .25 WASHER TPHS 8-32 X .25
$1.95
(40.7)
SQUARE NUT BLACK 1/4 - 20 SQUARE NUT BLACK 1/4 - 20
$1.95
(41)
SPLIT GRIP (E) LEFT SPLIT GRIP (E) LEFT
$11.95
(42)
SCREW BHCS 6-32 X .375 SCREW BHCS 6-32 X .375
$1.95
(43)
SPLIT GRIP (E) RIGHT SPLIT GRIP (E) RIGHT
$11.95
(44)
SCREW NYLON 10-32 X .25 PLUG POWER TUBE SCREW NYLON 10-32 X .25 PLUG POWER TUBE
$1.95
(45)
98 PS PICATINNY RAIL 98 PS PICATINNY RAIL
$29.95
(46)
O-RING CAST URETHANE 2-019, 90A O-RING CAST URETHANE 2-019, 90A
$2.95
(47)
98 BOLT HANDLE 98 BOLT HANDLE
$14.95
(48)
PIN GUIDE FLT HD 0.117 X 2.085 PIN GUIDE FLT HD 0.117 X 2.085
$4.95
(49)
ACT REAR BOLT ACT REAR BOLT
$29.95
(50)
ACT LINKAGE ARM ACT LINKAGE ARM
$3.95
(51)
ACT SPRING CUP ACT SPRING CUP
$13.95
(52)
ACT DRIVE SPRING ACT DRIVE SPRING
$4.95
(53)
ACT UPPER SPRING LONG ACT UPPER SPRING LONG
$4.95
(54)
ACT SPRING PIN ACT SPRING PIN
$7.95
(55)
ACT UPPER SPRING SHORT ACT UPPER SPRING SHORT
$4.95
(56)
ACT BUFFER O-RING ACT BUFFER O-RING
$1.95
